Titanium Ball Valve with ISO5211 Pad, TA2, DN200, PN16

China Titanium Ball Valve Manufacturer Shinjo Supplies Titanium Ball Valve with ISO5211 Pad, TA2, DN200, PN16.

Tags:

• Floating ball
• ISO5211
• Split body
• PN16
• EN 1092-2 Flange ends
• DN200 Ball Valve
• Special Alloy Valves
• Titanium Valves
• Titanium TA2

Valve Description:
Valve Type: Floating Ball Valve
Body Material: Titanium TA2.
Nominal Diameter: DN200
Pressure Rating: PN16
End Connection: RF Flange
Working Temperature: -29℃~+200℃.
Operation: Lever.
Titanium Alloy Ball Valve Futures:

• Titanium valve not only good corrosion resistance, but also light weight, high mechanical strength.
• Titanium valve in the atmosphere, fresh water, sea water, high temperature steam almost no corrosion.
• Titanium valve in aqua regia, chlorine water, hypochlorous acid, wet chlorine and other media have a good corrosion resistance.
• Titanium valves are also very resistant to corrosion in alkaline media.
• Titanium valve has very strong chloride ion (CI) resistance and excellent chloride ion corrosion resistance.
• The corrosion resistance of titanium valve in organic acid depends on the size of reducing or oxidizing acid.
• Corrosion resistance of titanium valve in reducing acid depends on whether there is corrosion inhibitor in the medium.

Titanium Alloy Material Grades:

ZTA1, ZTA2, ZTA3, ZTA9, ZTA10, ZTC4
TA1, TA2, TA3, TA9, TA10, TC4
Titanium Gr2, Gr3, Gr5, Gr6, Gr7, Gr12
Titanium GrC2, GrC3, GrC5, GrC6, Ti-Pd7B, GrC12
Titanium GrF2, Gr3F, GrF5, GrF6, GrF7, GrF12
