Proportioning Diaphragm Metering Pump
2JMX mechanical diaphragm metering pump has duplex pump head with one motor and gearbox. The two heads work individually, thus each head flow rate can be adjusted separately. It is an ideal pump for proportioning dosing.
Specifications:
1. Capacity range: 40 l/h -240l/h under 50Hz
2. Pressure range: 4-8 bars
3. Max processing temperature: from 70℃ (158℉)
4. Stroke adjustment: 0-100%
5. Suction lift: 1.5m
6. Accuracy: ±2% of set point
Materials:
1. Pump head: PVC, PTFE, SS304, SS316
2. Diaphragm: PTFE
3. Check valve: PVC, PTFE, SS304, SS316 (same as pump head selection)
4. Valve ball: Ceramic, SS304, SS316
Power Supply:
380V 3 phase on standard, single phase or other voltage on request; EX-proof motor is available on request.
Parameter Table:
Model |
50 Hz |
60 Hz |
Pressure |
Power
kW(HP) |
Flow
(lph) |
Flow
(gph) |
SPM |
Flow
(gph) |
Flow
(lph) |
SPM |
(Bar) |
(Psi) |
2JMX 40/0.8 |
40 |
10.6 |
48 |
12.7 |
48 |
58 |
8 |
116 |
0.37(0.5) |
2JMX 80/0.6 |
80 |
21 |
48 |
25 |
96 |
58 |
6 |
87 |
2JMX 120/0.5 |
80 |
21 |
48 |
25 |
96 |
58 |
5 |
73 |
2JMX 160/0.5 |
160 |
42 |
96 |
51 |
192 |
115 |
5 |
73 |
2JMX 200/0.4 |
200 |
53 |
96 |
63 |
240 |
115 |
4 |
58 |
2JMX 240/0.4 |
240 |
63 |
96 |
76 |
288 |
115 |
4 |
58 |
Standard Connection:
Model |
PVC |
PTFE |
SS |
2JMX40~2JMX80 |
6.5*10mm PE hose |
RC 1/2"F |
DN15 welding union |
2JMX120~2JMX240 |
DN15 glue union |
RC 1/2"F |
DN15 welding union |
