Specifications:
Butterfly Valve type: Triple Offset
Body material: Cast Steel
Size: DN50 to DN1400 mm
Pressure: PN63/100
End connection: RF Flange
Flange standard : EN 1092-1
Product Range:
Body Material: Stainless Steel, Carbon Steel, Bronze C95800, Alloy Steel, Titanium, 904l, Cast Steel.
Normal diameter: 2"~80" (DN50~DN2000).
End connection: Flanged, Butt Welded, Wafer, Lugged
Pressure range: PN10, PN16, PN25, PN40, PN63, PN100, 150LB, 300LB, 600LB
Flange standard : EN 1092-1, JIS, DIN, ANSI
API609 Triple Offset Butterfly Valve Structure Drawing:
PN63 Dimensions Tables:
DN |
L |
Flange Dimensions |
外形尺寸 |
Top Flange |
Weight(Kg) |
D |
D1 |
D2 |
f |
b |
Z-Φd |
4-W |
H0 |
H |
A |
B |
G |
ISO 5211 |
d0 |
h |
50 |
150 |
165 |
125 |
102 |
3 |
20 |
4-Φ18 |
--- |
82.5 |
195 |
50 |
144 |
180 |
F07 |
16 |
35 |
19 |
65 |
170 |
185 |
145 |
122 |
3 |
22 |
8-Φ18 |
--- |
92.5 |
210 |
50 |
144 |
180 |
F07 |
16 |
35 |
20 |
80 |
180 |
200 |
160 |
138 |
3 |
24 |
8-Φ18 |
--- |
100 |
230 |
50 |
144 |
180 |
F07 |
18 |
40 |
23 |
100 |
190 |
235 |
190 |
162 |
3 |
24 |
8-Φ22 |
--- |
117.5 |
250 |
50 |
144 |
180 |
F07 |
18 |
40 |
26 |
125 |
200 |
270 |
220 |
188 |
3 |
26 |
8-Φ26 |
--- |
135 |
295 |
63 |
200 |
300 |
F10 |
22 |
45 |
43 |
150 |
210 |
300 |
250 |
218 |
3 |
28 |
8-Φ26 |
--- |
215 |
340 |
80 |
230 |
350 |
F12 |
30 |
60 |
64 |
200 |
230 |
375 |
320 |
285 |
3 |
34 |
12-Φ30 |
--- |
220 |
390 |
80 |
230 |
350 |
F12 |
35 |
70 |
74 |
250 |
250 |
450 |
385 |
345 |
3 |
38 |
8-Φ33 |
4-M30 |
265 |
485 |
125 |
260 |
400 |
F14 |
40 |
80 |
119 |
300 |
270 |
515 |
450 |
310 |
4 |
42 |
12-Φ33 |
4-M30 |
290 |
490 |
125 |
260 |
400 |
F14 |
45 |
90 |
165 |
350 |
290 |
580 |
510 |
465 |
4 |
46 |
12-Φ36 |
4-M33 |
310 |
540 |
125 |
260 |
400 |
F16 |
50 |
100 |
259 |
400 |
310 |
660 |
585 |
535 |
4 |
50 |
12-Φ39 |
4-M36 |
340 |
620 |
160 |
290 |
500 |
F25 |
60 |
120 |
325 |
450 |
330 |
685 |
610 |
560 |
4 |
57 |
16-Φ39 |
4-M36 |
390 |
645 |
200 |
418 |
600 |
F25 |
70 |
130 |
366 |
500 |
350 |
755 |
670 |
615 |
4 |
57 |
16-Φ42 |
4-M39 |
415 |
670 |
200 |
418 |
600 |
F25 |
70 |
130 |
444 |
600 |
390 |
890 |
795 |
735 |
5 |
72 |
16-Φ48 |
4-M45 |
500 |
740 |
263 |
510 |
700 |
F30 |
90 |
160 |
661 |
700 |
430 |
995 |
900 |
840 |
5 |
64 |
20-Φ48 |
4-M45 |
580 |
900 |
263 |
510 |
700 |
F30 |
110 |
170 |
1096 |
800 |
470 |
1140 |
1030 |
960 |
5 |
72 |
20-Φ56 |
4-M52 |
665 |
975 |
333 |
550 |
800 |
F35 |
130 |
200 |
1492 |
900 |
510 |
1250 |
1140 |
1070 |
5 |
76 |
24-Φ56 |
4-M52 |
690 |
1010 |
333 |
550 |
800 |
F35 |
140 |
200 |
1823 |
1000 |
550 |
1360 |
1250 |
1180 |
5 |
80 |
24-Φ56 |
4-M52 |
755 |
1090 |
333 |
550 |
800 |
F40 |
150 |
200 |
2198 |
1200 |
630 |
1575 |
1460 |
1380 |
5 |
88 |
28-Φ62 |
4-M56 |
950 |
1365 |
374 |
590 |
900 |
F40 |
170 |
220 |
3087 |
1400 |
710 |
1795 |
1680 |
1600 |
5 |
98 |
32-Φ62 |
4-M56 |
1090 |
1475 |
374 |
590 |
900 |
F48 |
200 |
230 |
3940 |
